Honda VT500 fork brace

I designed a fork brace for my 1985 honda VT500. The part is no longer available. I sent the design to PCB way for CNC machining. The process was simple. The agent I was dealing with explained that I need to amend the design due to a clearance issue. I re uploaded my design and 2 weeks later it was in my hands. I can't recommend PCB way enough.




Sep 01,2026
