Hinge Cover

First time ordering machined parts online. Turns out exacty as I'd hoped and the chrome plating was perfect. The thin walls I had left in the design were very straight and I was able to use those features for a tight spring loaded fit on the hinges these were designed for. Quite expensive, but the quality and lead times were very good and I did not require my usual amount of following up for manufacturing thats required for engineered parts in the workplace. Totally recommend.

Oct 26,2023
