We needed an copper tab exposed on both sides for soldering purposes. I had requested that there be no polyimide and no stiffener in a certain region, so that it would be a strip of copper only. My request was not understood, so I got a region that had polyimide and was not plated. This was incorrect, I did not want plating removed, I wanted the polyimide removed. Otherwise a nice board.
