Embedded AI Device

This is my very first own designed PCB and I am so happy that I was able to do it. Basically, I am using this for my research study and I want it to look professional by designing a simple PCB. I placed the order on September 10 (or 11?) and I just received it today, September 24, 2026. It is relatively quick considering how close China is to the Philippines but nonetheless I chose the cheapest shipping option I could possibly pick and it is impressive that it took me 2 weeks or so to actually get my PCB. Just a quick note that if you are going to choose the "Global Direct Shipping" option upon checking out, please know that it may update very slowly like what I experienced. But either way, if you wanna save some money and not in rush to have your PCB, then try to consider that option as well, just keep in mind the thing I just said (It also depends on your address, but yeah). When it comes to the PCB itself, I am really impressed of how precise the cutouts are. On my design, the edge cutouts of my PCB isn't simply a rectangle or square, it has some subtle angled lines. Despite that, it is really a good one! Hoping I could make more personal projects in the future and might order another PCB. Thank you again, PCBWay.




Sep 24,2026
