Body

The quality of the parts is really excellent! I'm very happy with the result. I am especially impressed with the excellent tolerance between the Body part and Cover part. However, my one issue is the threading between the Tube part and the Body part. Those are supposed to be compatible threads, however I noticed that the threads lock and I cannot screw the Tube all the way into the Body. For now this is fine, because I am still able to use the assembly as originally intended. However, in case I need to make updates to the assembly, it would be necessary to check that the Tube and Body have compatible threads. Thank you!




Sep 02,2026
