Bluetooth Joystick Controller

I ordered this stencil with the small prototype PCB. It arrived with a few chads still in place, but these were easily popped out with tweezers. The thickness is perfect for applying solder paste with just a spatula and credit card for a squeegee. Hand placed the components for a perfect prototype first time. I have a few traces to fix, bit if I don't move the components I can use the same stencil for the next rev.
