A3054 Intraperitoneal Transmitter

This rigid-flex board came out perfectly. Six layers in the four 10-mm diameter rigid sections, separated by short flex cables of two layers, including flex cables with stiffened flex plugs at either end. We have assembled two of them by hand and all circuits are correct. The panel is well-designed also.
