3D Printer heatsink

The part came out dimensionally accurate, the surface finish was great, and the annodisation was stellar, all but one hole was perfectly sized and tapped, one of the sizes was oversized, a 4mm bore was drilled not an M4 thread in a smaller hole, but that could have been a mistake on my mechanical drawings.
