Octavo Systems OSD32MP1-BRK Prototyping Platform
The OSD32MP1-BRK is a small flexible prototyping platform for the STM32MP1 based SiP, the OSD32MP15x. At only 3in X 1.8in (75mm X 46mm), it provides easy access to the I/O of the STM32MP1 through a set of breadboard compatible headers. The OSD32MP1-BRK allows developers to quickly build a proof of concept that more closely resembles their actual system without the need to build their own custom hardware.
The OSD32MP1-BRK features the OSD32MP15x System in Package, a microSD slot, 32KHz crystal, a microUSB client port, and two 2×30 100 mill headers. The headers give access to 106 I/O on the STM32MP1 integrated into the OSD32MP15x SiP. It uses a 4 Layer PCB with low cost design rules and has no back side components.
Its minimal overhead and access to a wide range of I/O make the OSD32MP1-BRK the perfect platform for any designer looking for complete flexibility as they prototype their design.
The OSD32MP1-BRK is designed and manufactured by Allied Component Works, LLC, a member of the Octavo Systems partner network.
1.OSD32MP157C-512M-BAA
- STM32MP157C Dual Arm Cortex-A7 + M4
- 512MB DDR3 memory
- STPMIC1A power management
- EEPROM
- Oscillator
- Passive
2.Access to 106 I/O
- Two 2x30 100mil (2.54mm) headers
- Maximum flexibility to prototype designs
- Breadboard compatible
3.Micro USB port
4.STLink
5.UART
6.MicroSD card slot
7.32KHz crystal
8.4 layer design
9.No backside components
10.Compact 75mm x 46mm (3.0" x 1.8") form factor
