RGB LED PWM control with acellerometer, used to time flight and arc of thrown PCB

This was a first PCB. I made three mistakes that I fixed with cut and straps and bit bashing one SPI interface. Everything that PCBway did was correct! I must admit I was worried one chip was on incorrectly (the pin 1 marker was microscopic). But nope, pcbway were right and my layout was wrong! For a first prototype this worked very well. I will be sending version 0.2 soon.
