Zero Voltz
BRAZIL • + Follow
Edit Project
Components
|
M27C801-100F1STMicroelectronics
|
x 1 | |
|
Resistor 3,3k |
x 1 | |
|
Capacitor 22uf Eletro 16V |
x 1 | |
|
Capacitor 100nF (104) |
x 2 | |
|
PIC12F629Microchip
|
x 1 |
Description
SNES M27C801 HiRom 8Mib without save PCB Single Game
OBS: Just HiROM Games with a max ROM size of 8Mib
List :
1x UV Eprom M27c801
1x 22uf capacitor 16V (Eletro)
2x 100nF capacitors (104), you can change to 68nF
1x 3,3k resistor 1/4W, you can change to 2,5k
1x PIC12F629
Pcb work, I tested in games:
Bomberman 1
Bomberman 2
Dottie Dreads Noguht
IMPORTANT: Need order pcb with 1.2mm thickness, more than 1.2mm don't enter in snes
Mar 21,2024
206 views
SNES M27C801 HiRom 8Mib without save PCB Single Game
Can use this PCB HiROM board with a max ROM size of 8Mib, just a single game. This board was designed to use M27C801, without save
