Frogulator for GBC/MGB
The Frogulator is a replacement DC regulator for the Game Boy Color and Game Boy Pocket systems, when paired with an aftermarket backlit screen, i.e. one that does not rely on the 13.6V and -15V rails.
In addition to providing the 5V power rail for general system operation, it features a built in battery indicator, where the eyes of the frog go from green to red when the batteries in the system begin to run low.
Full details for the project including examples showing it running can be found on YouTube.
CAD-Custom parts and enclosures
Feb 21,2023
4,554 views
Frogulator for GBC/MGB
2 Layers PCB 55.8 x 44.6 mm FR-4, 1 mm, 1, HASL with lead, Black Solder Mask, White silkscreen
Replacement DC regulator for the Game Boy Color and Pocket with a built in battery indicator + forg.
4554
18
2
Published: Feb 21,2023
BOM(Bill of materials)
Centroid file
Purchase
Donation Received ($)
PCBWay Donate 10% cost To Author
File Last Updated: 2023/03/14 (GMT+8)
File update record
2023-03-1409:11:37
Gerber file is updated.
2023-02-2809:28:05
Parts List (BOM) is updated.
2023-02-2106:01:41
Gerber file is updated.
