OMEN Alpha (issue 4b)
I write a book about old computers. Oh, sorry: I mean "vintage computers" from the 80's. My primary goal is to show how one can build an 8bit computer from scratch.
It means: how to set up a CPU, how to connect memories, how to connect peripheral chips, and why to connect...
This computer is a "demo construction": A computer, based on 8085 CPU, with 32 kB of (EEP)ROM and 32 kB of RAM, serial connection and parallel ports. All should be as simple as possible. And here is a result.
See also: Details on Hackster.IO, details on Hackaday.IO, project sources on GitHub
Sep 15,2018
2,861 views
OMEN Alpha (issue 4b)
2 Layers PCB 100 x 80 mm FR-4, 1.6 mm, 1, HASL with lead, Green Solder Mask, White silkscreen
Better siklscreen, placing, and holes
