Datel Robotek (a robot control card for ZX Spectrum) re-created version
This is a re-creation of an interface card called "Datel Robotek" for the Sinclair ZX Spectrum computer. This card is long lost in the history and very hard to find as original now. I have designed the PCB according to the original schematics contained in the book "Make and Program Your Own Robots". The book also contains many type-in projects using this card written in Spectrum BASIC. There were some mistakes in the schematic, which I have corrected. This is a tested and working project. All the components are thru-hole type and their part numbers, orientations are clearly indicated in the silk screen, making the assembly very easy.
Code
Apr 17,2024
143 views
Datel Robotek (a robot control card for ZX Spectrum) re-created version
A re-creation of a long-lost, almost impossible to get interface card for the Sinclair ZX Spectrum computer.
