Jammer Bluetooth 2.4G

Proyecto de PCB para Jammer bloqueador inhibidor de señales Bluetooth y Wifi de 2.4G.

Proyecto patrocinado por PCBWay, muchas gracias PCBWay por el apoyo!

Es un diseño de PCB que permite usar 2 versiones de proyecto; una versión con 2 antenas usando cualquier ESP32 Devkit V1 de 30 patas o también la versión de 3 antenas con el ESP32 Devkit C de 38 patas.

Más detalle sobre el montaje https://youtu.be/OwNFFxtWJls

Diseño de PCB By Damián G. Lasso https://lasso-tech.com/ & https://ledfacil.com.ar/

Download Gerbers

Oct 09,2025

937 views

Jammer Bluetooth 2.4G

2 Layers PCB 104 x 70.5 mm FR-4, 1.6 mm, 1, HASL with lead, Black Solder Mask, White silkscreen

Jammer inhibidor bBluetooth 2.4G https://youtu.be/HmP36cwC-FA
